HEICO-LOCK WASHER - STEEL ( LARGE OD ) |
|
|
|
 |
|
| |
|
|
Inch |
|
|
|
Metric |
|
|
|
Standard |
| HEICO |
Metric |
Inch |
Inner
Ø |
Outer Ø |
Thick
ness |
~Weight 100
pairs |
Inner
Ø |
Outer Ø |
Thick
ness |
~Weight
100
pairs |
Pack
aging |
| Part# |
d
(inch) |
d
(inch) |
inch |
lbs |
d
(mm) |
D
(mm) |
mm |
kg |
(pairs) |
| HLB-3.5 |
M3.5 |
#6 |
0.154 |
0.354 |
0.071 |
0.13 |
3.9 |
9 |
1.8 |
0.06 |
200 |
| HLB-4 |
M4 |
#8 |
0.173 |
0.354 |
0.071 |
0.13 |
4.4 |
9 |
1.8 |
0.06 |
200 |
| HLB-5 |
M5 |
#10 |
0.213 |
0.425 |
0.071 |
0.24 |
5.4 |
10.8 |
1.8 |
0.11 |
200 |
| HLB-6 |
M6 |
|
0.256 |
0.531 |
0.098 |
0.44 |
6.5 |
13.5 |
2.5 |
0.2 |
200 |
| HLB-1/4" |
|
1/4" |
0.283 |
0.531 |
0.098 |
0.40 |
7.2 |
13.5 |
2.5 |
0.18 |
200 |
| HLB-8 |
M8 |
5/16" |
0.343 |
0.654 |
0.098 |
0.64 |
8.7 |
16.6 |
2.5 |
0.29 |
200 |
| HLB-3/8" |
|
3/8" |
0.406 |
0.827 |
0.098 |
1.01 |
10.3 |
21 |
2.5 |
0.46 |
200 |
| HLB-10 |
M10 |
|
0.421 |
0.827 |
0.098 |
0.97 |
10.7 |
21 |
2.5 |
0.44 |
200 |
| HLB-12 |
M12 |
|
0.512 |
1.000 |
0.134 |
2.00 |
13 |
25.4 |
3.4 |
0.91 |
100 |
| HLB-1/2" |
|
1/2" |
0.531 |
1.000 |
0.134 |
2.05 |
13.5 |
25.4 |
3.4 |
0.93 |
100 |
| HLB-14 |
M14 |
9/16" |
0.598 |
1.209 |
0.134 |
3.21 |
15.2 |
30.7 |
3.4 |
1.46 |
100 |
| HLB-16 |
M16 |
5/8" |
0.669 |
1.209 |
0.134 |
2.84 |
17 |
30.7 |
3.4 |
1.29 |
100 |
| HLB-18 |
M18 |
|
0.768 |
1.358 |
0.134 |
3.48 |
19.5 |
34.5 |
3.4 |
1.58 |
100 |
| HLB-3/4" |
|
3/4" |
0.787 |
1.535 |
0.134 |
4.84 |
20 |
39 |
3.4 |
2.2 |
100 |
| HLB-20 |
M20 |
|
0.843 |
1.535 |
0.134 |
4.47 |
21.4 |
39 |
3.4 |
2.03 |
100 |
| HLB-22 |
M22 |
7/8" |
0.921 |
1.654 |
0.181 |
7.28 |
23.4 |
42 |
4.6 |
3.31 |
50 |
| HLB-24 |
M24 |
|
0.996 |
1.909 |
0.181 |
9.92 |
25.3 |
48.5 |
4.6 |
4.51 |
50 |
| HLB-1" |
|
1" |
1.098 |
1.909 |
0.181 |
9.24 |
27.9 |
48.5 |
4.6 |
4.2 |
50 |
| HLB-27 |
M27 |
|
1.118 |
1.909 |
0.260 |
11.86 |
28.4 |
48.5 |
6.6 |
5.39 |
50 |
| HLB-30 |
M30 |
1 1/8" |
1.236 |
2.303 |
0.260 |
19.71 |
31.4 |
58.5 |
6.6 |
8.96 |
50 |
| HLB-33 |
M33 |
1 1/4" |
1.354 |
2.303 |
0.260 |
18.28 |
34.4 |
58.5 |
6.6 |
8.31 |
25 |
| HLB-36 |
M36 |
1 3/8" |
1.472 |
2.480 |
0.260 |
20.13 |
37.4 |
63 |
6.6 |
9.15 |
25 |
|
|
|
|
